Highlights
- • 20“ low step over E-Bike
- • Front hub motor with optimized controller
- • Elegant titanium-matt finish with contrasting elements (tires, handles & saddle)
- • Suspension seat post
- • 3 brakes (V- brakes + coaster brake)
- • Shimano 3-speed hub shifter/ Shimano Revo- Shift
- • Stable, foldable aluminum frame
- • Easily stowed thanks to intelligent quick- folding mechanism including foldable pedals & handlebar
- • Comfortable 20” x 2.125 tires
- • Clear, easy-to-use and readable LCD- bike computer
- • 5-step PAS up to 25 km/h
- • Li-ion battery 36 V/ 10.4 Ah for up to 80 km/ 50 miles*
- • Battery removable and lockable
- • About 22 kg weight including battery
- • Meets the requirements of the german StVZO
- • Designed in Germany, Made in EU
Subject to technical changes, errors and typographical errors.
*The range depends on the load, driving style and area of use.
Technical specifications
MECHANIC
Frame: Alloy
Rims: Alloy, black
Tires: 20“ x 2,125/ 57-406, brown side wall, reflective stripes
Shift lever: Shimano Nexus 3 with coaster brake and Revo shifter
Brakes (front/ rear): V-brakes, additional coaster brake
Headset: Semi integrated
Max. payload: 100 kg
DRIVE
Engine: AKM 100SX, front hub motor, DC 36 V/ 250 W, 50 Nm, brushless, maintenance free, IP65
Battery: 36 V/ 10,4 Ah Lithium- Ion battery w. integrated BMS and battery status indicator
Sensors: Cadence- & speedsensor
Driving modes: 5 level PAS, PAS off, push assistance
Bike computer: KD21C LC-Display, 3 buttons, backlight, IP65 Functions: SPEED, ODO, TRIP, AVG/ MAX SPEED, TRIP TIME, PAS LEVEL (0- 5), Battery, Power output, Push Assistance, Lights on/ off, Auto Power Off, Error code info
Charger: Worldwide useable switching power supply (AC 100 – 240 Volt), 42 V, 2 A
Charging time: about 4- 6 h
Range: Up to 80 km(1) / 50 miles(1)
Max. speed (PAS): max. 25 km/h
Brake cut- off sensors: Yes
LIGHTING
Lamps/ reflectors: LED- head- and rear- lights with integrated reflectors, Fully EPAC powered,
Pedals w. integrated reflectors,
Tires with circumferential reflector stripes
FURTHER CONFIGURATION
Mudguards: Yes
Kickstand: Yes, kickstand at bb axle
Pedals: Alloy, Wellgo, foldable
Battery removable: Yes
Battery lockable: Yes
Charging if installed/ removed: Yes / Yes
Battery indicator: Yes, integrated in battery + computer
Additional battery: Optional (10 Ah, up to 80 km (50 miles)(1) or 13 Ah, up to 100 km (60 miles)(1) )
Chain protection: Yes
Luggage carrier: Yes (max. 25 kg payload)
Saddle: Selle Royal, brown
Grips: Selle Royal, brown
Bell: Yes, integrated on brake lever
Sprung seat post: Yes (Promax, adjustable)
Suspension fork: No
Bottle cage: No
Carry bag: Optional
Handlebar bag: Optional
SIZE / WEIGHT
Size (unfolded): About 1600 x 160 x 1100 mm (L x B x H, w/o pedals/ handlebar), About 1600 x 610 x 1100 mm (L x B x H)
Size (folded): About 800 x 430 x 700 mm (L x B x H)
Wheel size: 24“ x 2,125
Handlebar height: 940 – 1060 mm
Handlebar: 610 mm
Saddle height: 710 – 890 mm
Seat post: Ø 28,6 mm
Wheelbase: 1000 mm
Chassis clearance: 95 mm (till chainwheel protector)
Framesize: 424 mm
Weight incl. battery: about 22 kg
Battery weight: about 3 kg (10,4 Ah battery)
Color: Titanium- matte frame, black- matte components, brown saddle/ tires/ grips
SCOPE OF DELIVERY: Foldable E-Bike, EU charger, battery with 2 keys, User manual (multilingual
REPLACEMENT BATTERY: 10,4 Ah/ 36 V: Part number 2 008 020 111 050, 13 Ah/ 36 V: Part number 2 008 020 111 051
CERTIFICATIONS: EPAC DIN EN 15194:2017, CE, StVZO, UN38,3
LOGISTICAL DATA(2):
Box dimensions: about 845 x 431 x 740 mm (L x W x H)
Box weight: about 3,5 kg carton, 0,1 kg foam, 0,01 kg PVC (foil, cable ties…)
Weight total: about 25 kg
Customs tariff number: 87116010
(1) The range depends on the load, driving style and area of use
(2) Subject to modification
