Highlights
- • Blaupunkt 20“ design bike in color racing- orange/ black
- • Stable, foldable Magnesiumframe
- • Easily stowable thanks to intelligent quick release mechanism incl. foldable pedals & handlebar
- • Magnetlock for secure folding
- • Transportation wheel
- • Tektro disc-brakes
- • 6 gear Shimano SIS derailleur
- • Comfortable 2.125 tires
- • LCD-computer with 3- step PAS up to 25 km/h
- • Li-Ion battery 36 V/ 10,5 Ah with short charge time
- • Battery removable/ lockable
- • Range up to 70 km/ 45 miles*
- • Only about 21 kg weight with battery
- • Meets the requirements of german StVZO
- • Designed in Germany, Assembled in EU
*The range with one battery charge depends on many factors, such as: Support level used, driving speed, physical fitness and personal performance of the driver, shifting behavior of the driver (if gearshift is available), road conditions, wind conditions, driver’s seating position, system weight, temperature.
Technical specifications
Frame: Magnesium alloy
Rims: Magnesium, black powdered
Tires: 20“x 2.125
Shift lever: Shimano 6- gear SIS derailleur (44T / 14T-28T )
Brakes (front/ rear): Tektro disc brakes, mechanical, 160 mm
Headset: Semi integrated
Max. payload: 100 kg (incl. driver)
DRIVE
Engine: Rear hub motor Xiongda XD-20GS, DC 36 V/ 250 W, 50 Nm, IP54, brushless, maintenance free
Battery: 36 V/ 10,5 Ah LG- Lithium- Ion battery w. integrated BMS
Controller: 36 V/ 15 A DC
Sensors: Cadence- & speed sensor
Driving modes: 3 level PAS/ PAS off
Bike computer: LC- Display wit 3 function keys, backlight. Functions: Speed, ODO, TRIP, TIME, PAS LEVEL, battery, lights, auto- power- off, error display
Charger: Switching power supply (AC 100 – 240 Volt), 42 V, 2 ACharging time: about 4- 6 h
Range: Up to 70 km/ 45 miles (1)
Max. speed (PAS): max. 25 km/h
LIGHTING
Lamps/ reflectors: LED- headlight with reflector, EPAC powered Rechargeable USB LED- battery rear light at saddle stem Z- reflector, Pedals w. integrated reflectors
Tires with circumferential reflector stripes
FURTHER CONFIGURATION
Mudguards: Yes, included accessories
Kickstand: Yes, left sided at rear axle’
Pedals: Foldable
Battery removable: Yes
Battery lockable: Yes
Charging if installed/ removed: Yes / Yes
Battery indicator: Yes, computer display
Additional battery: Optional
Chain protection: Yes, integrated
Luggage carrier: No
Bell: Yes, integrated on brake lever
Sprung seat post: No
Suspension fork: No
Carry bag: Optional
Handlebar bag: Optional
SIZE / WEIGHT
Size (unfolded): About 1530 x 570 x 1080 mm (L x B x H)
Size (folded): About 850 x 500 x 600 mm (L x B x H)
Wheel size: 20“x 2,125
Handlebar height: 1040 mm
Handlebar: 570 mm
Saddle height: 870- 930 mm
Seat post: Ø 31.6 mm, 300 mm (optional 400 mm)
Wheelbase: 1010 mm
Chassis clearance: 200 mm (till transport wheel)
Framezize: 600 mm
Weight incl. battery: about 21 kg
Battery weight: about 1.5 kg
Color: racing-orange/ black
Scope of Delivery: E-Bike, Charger, Rechargeable battery tail light (with micro- USB cable, power adaptor not included), Mudguards, Battery with 2 keys, User manual (DE, EN, IT, PL, CS, DA, EL, FR, NL, SV)
Replacement Battery: Partnumber 2 008 020 111 069
Certifications: EPAC DIN EN 15194:2017, CE, StVZO, UN38,3, IPX4
LOGISTICAL DATA (2)
Box dimensions: about 850 x 430 x 640 mm (L x W x H)
Box weight: about 4 kg carton, 0,1 kg foam 0,01 kg PVC (foil, cable ties…)
Weight total: about 26.5 kg
Customs tariff number: 87116010
*The range depends on the load, driving style and area of use
(2) Subject to modification
